It is suitable for washing all kinds of films and woven bags with silt content of up to 80%.

Circulating water is used to ensure the washing effect and control the water flow and evaporation water volume.

Technical features

The pre-shreding and pre-washing system efficiently removes most of the silt and other impurities, protects the subsequent equipment, and greatly improves the service life of the crushing and washing system. The core parts of the pretreatment module adopt a wear-resistant design to ensure the continuous operation of the system for a long time

The washing pool roller is designed for high-pressure underwater washing to remove residual impurities to the greatest extent; claw-type uniform discharge ensures uniform discharge while controlling the water content, providing a technological basis for the dehydration module.

The high-speed centrifugal washing system applies corresponding blade hitting force to different materials at the most suitable rotation speed to achieve the best washing effect.

The film drying technology combined with centrifugal dehydration, screw extrusion drying and high-temperature hot air strictly controls the water content of the finished product within 5%, which is suitable for high-quality granulation requirements.

The whole line is automatically controlled by PLC, and the operation between the units of the system is associated, which maximizes the production capacity and has the function of predicting possible abnormal situations to ensure system security to the greatest extent.

Scope of application

Agricultural film

Household waste sorting film

Packaging film

Woven bags
